3M是國際最的導電膠帶制造商品牌, 各種不同厚度,不同導電性,不同粘性的導電膠帶的牌號多大400多個,為全球絕大多數電子品牌產品設計,組裝提供的EMI屏蔽和接地解決方案.
3M導電膠是3M EMC電磁兼容產品一個大的分枝, 除了導電膠膠, 3M EMC電磁兼容產品家族還為電子制造提供導電襯墊,電磁吸波材料,透明電磁屏蔽膜等產品提供解決方案.
所謂導電膠, 通常是在導電基帶涂布一層膠粘劑,做成具有粘接和屏蔽功能的膠帶產品.為了提高導電膠的導電性能, 往往在膠粘劑層中添加各類結構的導電粒子,形成具有導電性的導電膠粘劑, 是電子產品電磁兼容的必備解決方案.
3M導電膠的類型異向?qū)щ娔z膜產品的應用介紹:
7303、5363用于軟板連接到PCB上，及電極與電線間的連接，主要是手機、數碼相機、筆記本等數碼產品 裝配用，用于替代錫焊和連接器等；7379為FOG的LCM模組專用，用良好的粘結和導通性；9713、9703、9705用于柔性線路板、印刷線路板、EMI/RFI屏蔽罩與墊片的連接、粘結接地。
3M-9703(Z軸異向?qū)щ娔z帶,厚度:0.05mm)/9713(XYZ軸全向?qū)щ娔z帶,厚度:0.08mm)導電薄膜，具有良好的機械性能、導電性及環境穩定性等要求．
1 在將EMI電磁屏障粘貼與電子元件上3M-9713(XYZ軸導電薄膜)使用創新的導電纖維,以提供高粘性及更好的導電性質;
2 在軟性線路板上的連結上,3M-9703(Z軸異向?qū)щ姳∧?/span>)讓電流僅在垂直厚度方向中導通;
3 在連結軟性電路板到液晶面板、印刷電路板或者其他種類的軟性電路板,使用3M-9703(Z軸異向?qū)щ姳∧?/span>)膠帶,可減少成本、材料及無需焊接的特點.
4 分為Z-Axis及XYZ-Axis兩大類，前者適用于柔性線路板與硬質線路板，ITO玻璃等連接導通；后者廣泛適用于抗屏蔽應用，具有比金屬更良好的導電性能及易于加工，操作。9703/7303/5303導電膠帶：
Z-Axis，適用于柔性線路板與硬質線路板，ITO玻璃等連接導通。
5 9713 XYZ-Axis， 廣泛適用于抗屏蔽應用，具有比金屬更良好的導電性能及易于加工，操作。
2. 導電金屬箔膠帶
2-1 導電銅箔膠帶
定義: 通常是采用銅箔作為基帶制成的具有導電性的膠帶;
典型的產品牌號有:
單面的: 1181, 1188, 1189, 508SN,1194, CEC-3, EC1203等;
雙面的: CEC-2, EC1206,
帶絕緣膜的: ECP1801, CU1250等
壓紋的: 1245, 1345, 2245, 2345等
特點: 高導電性,帶離型紙供貨,便于模切和操作
2-2 導電鋁箔膠帶
定義: 通常是采用鋁箔作為基帶制成的具有導電性的膠帶;
典型的產品牌號有:
單面的: 1120, 1171, 1170, 1178, 1179, 300PL等;
雙面的:Al-25DC, 7772等;
帶PET膜的: CEAP-4B, CEAP-5B, CEAP-6B, CEAP-6C, C40BH,C40BM, DCN30AP等;
特點: 黑色, 超薄, 無殘膠, 可返工等
